S3

Frame Aircraft‐grade Aluminum Alloy, Invisible Wire Design
Dimension ( LxWxH ) 1280x485x1150mm (unfold)
Rider Recommended Age 14+ years
Rider Required Height 120‐200cm (3'11" ‐ 6'6")
IP Rating IPX7 for Battery & Controller & IoT & Motor, and All Wateproof Cable Connector.
Payload 25~120 kg ( 55~264 lbs )
Max. Climbing Angle Approx. 16°
Operating Temperature "‐10°C ~ 40°C (14 ~ 104°F)
Storage Temperature "‐20°C ~ +50°C ( ‐4°F~122°F )
Battery 36V DC, 14.5Ah, 522Wh, 18650 Samsung Lithium Cells
Typical Mileage Approx. 45 km (28.13 miles)
Charger AC100~240V input 50‐60Hz, 84W
Charging Time 5~6 Hours
Motor Powerful Waterproof Motor, Max Torque 23 N∙m
Rated Power 450 W
Max. Power 750 W
Max Speed (Km/h) Approx. 25 km/h (15.5 mph ) (20 km/h for German Standard)
Shock Absorber Double Arm Shock Absorption
Front & Rear Tire 10inch Non‐inflatable Tire Filled with Composite Material
Front Light 1.5W Double High Brightness Lighting (K‐mark certificated for German Standard)
Rear Light Always on Red Light, Flash During Brake, Independent Control for Turning Light
Brake Mode Front & Rear Drum Brake and Rear EABS
Battery Managment System Over‐heating, short circuit, over‐current, over‐charge,abnormal temperature protection
Net Weight Approx. 24 kg ( 52.15 lbs )
Container Loading 72 pieces/20'GP, 200 pieces/40'HQ
